Đang được cập nhậpSUREFIRE II 3-PHASE
Đặc điểm nổi bật
Đang được cập nhậpChi tiết sản phẩm
SKU SureFire II 3-Phase
| Output Volume – 115 VAC, 230 VAC (max.) | 250cc/min @ 60 Hz 210cc/min @ 50 Hz |
|
| Output Volume – 24 VDC (max.) | 250cc/min | |
| Output Pressure (max.) | PDI | 450 psi (31 bar) |
| SLR | 75 psi ( 5 bar) | |
| Pressure Switch Setting 1 | PDI | Closes at 290 psi (20 bar) |
| SLR | Closes at 290 psi (20 bar) | |
| Lubricant Viscosity | Standard Oil version | 20 to 1500 cSt @ operating temperature |
| Light Oil version | 5-40 cSt @ operating temperature | |
| Soft Greases² | NLGI grade 000 - NLGI grade 00 (40,000 cSt max) |
|
| Reservoir Fill Screen (oil only) | 40 mesh, removable | |
| Reservoir Volume | 2 liter 3 liter 6.0 liter 12.0 liter |
|
| Reservoir Material | Luran (Blue Tint) for 2, 3 and 6 liter Steel for 2, 3, 6 and 12.0 liter |
|
| Motor Voltage Options | 100/115 VAC 50/60 Hz 200/230 VAC 50/60 Hz (single-phase) 24 VDC |
|
| Motor Power Requirement³ | 100/115 VAC | 1.0 amps |
| 200/230 VAC (single-phase) | 0.70 amps | |
| 24 VDC | 2.4 amps | |
| Operating Temperature Range | 40°F through 105°F (5°C through 40°C) | |
| IP Enclosure Rating | IP-54 | |
| Electrical Fitting | Liquid tight | |
| Output Connection (x2, one each side) | G 1/4 BSPP | |
| Return Line Connection | G 1/4 BSPP | |
| Single (main) Feed Line | 6mm O.D. minimum recommended | |
